Grænseflade
- Kommunikation: 10/100/1000 Mbps Ethernet
- Protokol: Modbus TCP, TCP/IP, UDP, ICMP og ARP
- LED-indikering: LED for strøm og Ethernet-linkstatus
- Isolation voltage 3750Vrms
Digital input
- Input channels 5
- Input typ: single ended with common source/ ground
- Dry contact :
- logic level 1 (inactive) : open
- logic level 0 (active): Close till GND
- Wet contact :
- logic level 0 (inactive) : +2VDC max
- logic level 1 (active): +4V till 30VDC max
- Logic level status can be inversed via ASCII/Modbus command
- Dry contact :
- Counter Input: 500Hz counter input (32-bit+1-bit överflow)
Digital udgang:
- Output channels: 3 Relay output
- Relay typ: RL1/Form A, RL2/3 Form C
- Relay contact rating: 0.6A/125Vac, 2A/30Vdc
- Surge Strength: 500V
- Operate Time: 3mS max
- Reläase Time: 2mS max
- Min Life: 5*10 ops
- Pulse output: Each channel supports 500Hz pulse output
Strømkrav:
- Consumption: 1.8W
- Strømindgang: 10~30VDC (ureguleret)
- Humidity: 5~95% RH, non-condensing
